Are you trying to figure out what size softener you'll need? You've come to the right place. The chart below will help you to determine which of our water softeners are the right fit for your home. Then take a look at the next section to help you figure out what grain capacity you need.
Model |
Capacity |
Hardness* |
Ferrous Iron* |
Warranty: |
18,500 grain |
65 gpg |
3 ppm |
- 1 Year Parts/Warranty (5 Yr Extension Available) - 3 Year Electronic Control Board - 10 Yr Salt and Resin Tanks |
|
30,000 grain |
95 gpg |
8 ppm |
||
40,000 grain |
125 gpg |
10 ppm |
||
44,000 grain |
140 gpg |
12 ppm |
||
48,000 grain |
160 gpg + Sediment* |
12 ppm |
- 2 Year Parts/Warranty (10 Yr Extension Available) - 3 Year Electronic Control Board - 10 Yr Salt and Resin Tanks
|
|
31,000 grain |
120 gpg + Chlorine & Sediment* |
3 ppm |
*Hardness and Clear Water (Ferrous) Iron Reduction Values.
*Sediment - the filters are designed the reduce large sediment, visible to the naked eye. There is no rated micron size.
How to Choose a Softener?
We'll need to do a little math. Let’s start with some calculations to determine the Unit Capacity that best fits your household:
What unit works best for the above example?
Looking at the available units below, we would recommend the WHES30 or WHESFC for the example above. The Grain Capacity of both units are over the family’s minimum 28,800 grain capacity needed, so those softeners would be the most efficient for the family.
Model | Grain Capacity |
WHES18 WHES30 WHESFC WHES40 WHES44 WHES48 |
18,000 30,000 31,000 40,000 44,000 48,000 |
